Centric 320.51033 - Centric GCX Rotor with Partial Coating
$3449
MSRP: $35.48
Save: $0.99
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
Misc Holes [cntrc] | 3 |
Max Pb Drum Dia [cntrc] In | 6.654 |
Product Grade [cntrc] | Premium |
Disc Mounting [cntrc] | Floating / DIH |
Weight [cntrc] Kgs | 4.070 |
Weight [cntrc] Lbs | 8.950 |
California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
Max Pb Drum Dia [cntrc] Mm | 169.000 |
Discard Thickness | 0.331 IN |
Discard Thickness | 8.400 MM |
Nominal Thickness | 10.000 MM |
Nominal Thickness | 0.394 IN |
Disc Finish | Partially Coated |
Hat Finish | Coated |
Overall Height | 61.200 MM |
Overall Height | 2.409 IN |
Outside Diameter | 10.315 IN |
Outside Diameter | 262.000 MM |
ABS Tone Ring Included | No |
Surface Type | Smooth |
Solid Or Vented Type Rotor | Solid |
Nominal Drum Diameter | 6.614 IN |
Nominal Drum Diameter | 168.000 MM |
Bearings Included | No |
Center Hole Diameter | 76.000 MM |
Center Hole Diameter | 2.992 IN |
Mounting Bolt Hole Circle Diameter | 114.300 MM |
Mounting Bolt Hole Circle Diameter | 4.500 IN |
Stud/Lug Hole Quantity | 5 |
Stud/Lug Hole Diameter | 12.500 MM |
Stud/Lug Hole Diameter | 0.492 IN |
Additional Information
Harmonized Tariff Code (HTS) | 8708305030 |
NAFTA Preference Criterion Code | B |
Country of Origin (Primary) | CN |
UPC | 889590301571 |
Part Interchanges
CENTRIC 320.51033 Cross Reference
We have 2 alternatives for the 320.51033 by CENTRIC:
