CENTRIC part description

Product Description

Centric GCX Rotor with Partial Coating

Features & Benefits

  • RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs

Product Attributes

Disc Mounting [cntrc] Floating
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 8.410
Misc Holes [cntrc] 0
Product Grade [cntrc] Premium
Weight [cntrc] Lbs 18.500
Vane Style [cntrc] Straight
Discard Thickness 30.860 MM
Discard Thickness 1.215 IN
Nominal Thickness 32.700 MM
Nominal Thickness 1.287 IN
Disc Finish Partially Coated
Hat Finish Coated
Overall Height 65.600 MM
Overall Height 2.583 IN
Outside Diameter 11.610 IN
Outside Diameter 294.900 MM
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 3.094 IN
Center Hole Diameter 78.600 MM
Mounting Bolt Hole Circle Diameter 139.700 MM
Mounting Bolt Hole Circle Diameter 5.500 IN
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 16.000 MM
Stud/Lug Hole Diameter 0.630 IN

Additional Information

Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 889590302301

Part Interchanges

CENTRIC 320.67029 Cross Reference

We have 3 alternatives for the 320.67029 by CENTRIC:
