Centric 320.44175 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 211.000 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] In | 8.307 |
| Hat Id [cntrc] Mm | 209.500 |
| Vane Style [cntrc] | Straight |
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 14.550 |
| Misc Holes [cntrc] | 8 |
| Weight [cntrc] Kgs | 6.600 |
| Hat Id [cntrc] In | 8.248 |
| Discard Thickness | 0.630 IN |
| Discard Thickness | 16.000 MM |
| Nominal Thickness | 18.000 MM |
| Nominal Thickness | 0.709 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 68.100 MM |
| Overall Height | 2.681 IN |
| Outside Diameter | 12.287 IN |
| Outside Diameter | 312.100 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 8.256 IN |
| Nominal Drum Diameter | 209.700 MM |
| Bearings Included | No |
| Center Hole Diameter | 4.252 IN |
| Center Hole Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 139.700 MM |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 14.400 MM |
| Stud/Lug Hole Diameter | 0.567 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590301250 |
Part Interchanges
CENTRIC 320.44175 Cross Reference
We have 3 alternatives for the 320.44175 by CENTRIC:
