CENTRIC part description

Product Description

Centric GCX Rotor with Partial Coating

Features & Benefits

  • RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs

Product Attributes

Vane Style [cntrc] Pillar
Misc Holes [cntrc] 3
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Product Grade [cntrc] Premium
Weight [cntrc] Kgs 10.000
Disc Mounting [cntrc] Floating
Weight [cntrc] Lbs 22.000
Discard Thickness 1.209 IN
Discard Thickness 30.700 MM
Nominal Thickness 32.000 MM
Nominal Thickness 1.260 IN
Disc Finish Partially Coated
Hat Finish Coated
Overall Height 52.000 MM
Overall Height 2.047 IN
Outside Diameter 323.000 MM
Outside Diameter 12.717 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 70.800 MM
Center Hole Diameter 2.787 IN
Mounting Bolt Hole Circle Diameter 114.300 MM
Mounting Bolt Hole Circle Diameter 4.500 IN
Stud/Lug Hole Quantity 6
Stud/Lug Hole Diameter 14.300 MM
Stud/Lug Hole Diameter 0.563 IN

Additional Information

Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 889590301830

Part Interchanges

CENTRIC 320.62082 Cross Reference

We have 3 alternatives for the 320.62082 by CENTRIC:
