Centric 320.34097 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Hat Id [cntrc] In | 6.843 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.070 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 17.750 |
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 1 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] Mm | 173.800 |
| Discard Thickness | 18.400 MM |
| Discard Thickness | 0.724 IN |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 78.800 MM |
| Overall Height | 3.102 IN |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 7.283 IN |
| Nominal Drum Diameter | 185.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 2.953 IN |
| Center Hole Diameter | 75.000 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.400 MM |
| Stud/Lug Hole Diameter | 0.646 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590300765 |
Part Interchanges
CENTRIC 320.34097 Cross Reference
We have 3 alternatives for the 320.34097 by CENTRIC:
