CENTRIC 320.33136 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.33136 Specifications
Product Attributes
| Hat Id [cntrc] In | 5.882 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 149.400 |
| Weight [cntrc] Lbs | 22.950 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 10.400 |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 1 |
| Vane Style [cntrc] | Pillar |
| Discard Thickness | 1.102 IN |
| Discard Thickness | 28.000 MM |
| Nominal Thickness | 30.000 MM |
| Nominal Thickness | 1.181 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 52.200 MM |
| Overall Height | 2.055 IN |
| Outside Diameter | 320.000 MM |
| Outside Diameter | 12.598 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 68.000 MM |
| Center Hole Diameter | 2.677 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.200 MM |
| Stud/Lug Hole Diameter | 0.598 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 889590300635 |
CENTRIC 320.33136 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980941FZN, 980941R, 980941 |
| N/A | HC34499X |
CENTRIC 320.33136 Cross References
We have 3 alternatives for the 320.33136 by CENTRIC:
