Centric 320.66071 - Centric GCX Rotor with Partial Coating
$10699
MSRP: $150.11
Save: $43.12
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Weight [cntrc] Lbs | 28.990 |
| Weight [cntrc] Kgs | 13.180 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 38.000 MM |
| Discard Thickness | 1.496 IN |
| Nominal Thickness | 40.000 MM |
| Nominal Thickness | 1.575 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 146.200 MM |
| Overall Height | 5.756 IN |
| Outside Diameter | 345.500 MM |
| Outside Diameter | 13.602 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.846 IN |
| Center Hole Diameter | 123.100 MM |
| Mounting Bolt Hole Circle Diameter | 165.000 MM |
| Mounting Bolt Hole Circle Diameter | 6.496 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 16.200 MM |
| Stud/Lug Hole Diameter | 0.638 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590297218 |
Part Interchanges
CENTRIC 320.66071 Cross Reference
We have 2 alternatives for the 320.66071 by CENTRIC:
