Sealed Power R-10616 30 - "Speed Pro" Engine Piston Ring Set - Premium
- Part Number
- R-10616 30
- Manufacturer
- SEALED POWER
- Description
-
"Speed Pro" Engine Piston Ring Set - Premium
details
$17499
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
SEALED POWER part description
Product Description
Engine Piston Ring Set
Application Summary
LS7 7.0L
Features & Benefits
- Introducing the all new Pro-MetricTM piston ring sets featuring lighter weight top rings, ductile iron second rings with a Napier-style groove and a patented curved vent oil ring for uniform contact pressure and reduced friction
- Top ring contain a stainless steel nitrided treatment providing reduced friction and lower chance of micro welding
- Napier-style second ring provides enhanced oil control and is compatible with all bore materials
- Chrome oil rings complete with a stainless curved vent expander ring are coated with a corrosion-resistant surface maintaining consistent pressure and uniform tension
- Application specific design to ensure a perfect fit and correct operation for unsurpassed quality that you can trust
Product Attributes
| Oversized | Yes |
| Oversized Amount | 0.030 IN |
| Outside Diameter | 4.1550 IN |
| Cylinder Quantity | 8 |
| Bore Diameter | 4.1250 IN |
| Oil Ring Design | Flex |
| 2nd Ring Face Design | Napier |
| Top Ring Face Design | Barrel Face |
| 2nd Ring Material | Martensitic Ductile |
| Top Ring Material | Steel Nitride |
| Oil Ring Tension | Low |
| Oil Ring Width | 3.00 MM |
| 2nd Ring Width | 1.20 MM |
| Top Ring Width | 1.20 MM |
| File Fit | No |
| Outside Diameter (In) | 4.1550 |
| Part Description | Engine Piston Ring Set |
| Ring Set Groove Widths (mm) | 1.2 x 1.2 x 3.0 |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (HTS) | 8409910011 |
| UPC | 00019826222251 |
Part Interchanges
Speed-Pro® is the go-to brand not only for racers and performance enthusiasts but also for those who are cruising down the road day in day out. With its engineering expertise, advanced technologies, and industry-leading manufacturing facilities and techniques, Speed-Pro sets the bar higher for other manufacturers of pistons, engine bearing parts, and performance engine components. The engine solutions from Speed-Pro are meticulously designed and crafted to boost horsepower production and make engine rebuild an easy feat. Since its establishment, this brand has continuously improved and refined its operations and quality control measures to maintain high quality standards and satisfy customers’ requirements and demands.
