Name: Reach Cooling 42-10476 Western Star 4900 SERIES 2010-2016
SKU: 4210476
Price: 975.49 USD
Availability: InStock

REACH COOLING part description

Western Star 4900 SERIES 2010-2016 reference 42-10472 w/o toc Compare

Make	Western Star
Model	4900
Year	2010, 2011, 2012, 2013, 2014, 2015, 2016

Product Description

Western Star 4900 SERIES 2010-2016

Application Summary

Western Star 4900 SERIES 2010-2016

Features & Benefits

Our fin edges are folded for increased stability and heat disbursement properties.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Folded fin edges increase stability and heat disbursement properties.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Core Width	41.625 IN
Core Thickness	2.25 IN
Core Height	39 IN
Inlet Diameter	2 1/2 IN
Transmission Oil Cooler Distance between Fittings	12 IN
Outlet Diameter	2.5 IN
Core Height	991 MM
Outlet Location	Lower Right
Core Thickness	57.15 MM
Down Flow Or Cross Flow Type	Down Flow
Outlet Diameter	63.5 MM
Transmission Oil Cooler Distance between Fittings	304.8 MM
Transmission Oil Cooler Included	Yes
Transmission Oil Cooler Distance between Fittings	304.80 MM
Radiator Cap Included	No
Core Thickness	57.15 MM
Core Width	1057.275 MM
Core Width	1057 MM
Inlet Diameter	63.5 MM
Engine Oil Cooler Included	No
Core Height	990.6 MM
Frame Included	No
Outlet Diameter	64 MM
Fitting Connection Type	Pipe connect
Inlet Diameter	63.5 mm
Inlet Location	Upper Right

Additional Information

Warranty Special	12 Months
Country of Origin (Primary)	CN
UPC	06941099903527
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10476 Cross Reference

We have 19 alternatives for the 42-10476 by REACH COOLING:

Fits Vehicles

Western Star 4900FA (2010-2015)
Western Star 4900EX (2010-2015)
Western Star 4900SA (2010-2015)
