(888) 312-8812 Login SignupMERITOR KIT225222 TRLR EX225 BRK
MSRP: $3,881.50
$2,08599
Save $1,795.51
+$880.00 core deposit
Total price w/ core: $2,965.99
In Stock
Get it by Thursday, Feb 5
MERITOR KIT225222 Part Description
| Application | Simple bolt-on replacement for Bendix® and Wabco® trailer calipers.  Can reuse existing brake chamber, rotor and torque plate.  Has been test fitted and approved by Meritor engineering on Hendrickson® Intraax AANT 23K AAT 23K and AAT 25K suspensions. |
| Basic Troubleshooting | Refer to Reference Material |
| Features | Gear-driven adjuster gives optimal running clearance and even pad wear.  Fewer ingress paths for water than competitor’s twin piston caliper, and 1 lb lighter.  Manual adjuster stem has 30lb. maximum torque, which is almost twice as high as break point |
| VMRS Code | 013-017-000 |
Meritor Disc Brake Caliper
Bring back your truck's optimum braking performance with the Meritor disc brake caliper. Manufactured using high-grade materials and 100% pressure tested, this caliper is durable enough to withstand the rigors of heavy-duty truck applications.
Features & Benefits
- Unique caliper design minimizes ingress points to prevent contamination
- Built tough to meet the braking demands of heavy-duty trucks, trailers, and tractors
- Helps achieve in-line braking stability for smoother and safer stops
- 100% tested through a combination of internal and independent external testing
- With a durable gear-driven adjuster mechanism to maintain correct running clearance
MERITOR KIT225222 Specifications
Product Attributes
| Application | Simple bolt-on replacement for Bendix and Wabco trailer calipers. Can reuse existing brake chamber, rotor and torque plate. Has been test fitted and approved by Meritor engineering on Hendrickson Intraax AANT 23K AAT 23K and AAT 25K suspensions. |
| Axial Or Radial Mount | Axial |
| Basic Troubleshooting | Refer to Reference Material |
| Brake chamber angle | 12 degrees |
| Brand | Meritor Genuine |
| Carrier Mounting Holes | 6 |
| Chamber Mount | Axial 12 degrees |
| Chamber Position | Axial |
| Distance A-b | 3 1/4 in. |
| Features | Gear-driven adjuster gives optimal running clearance and even pad wear. Fewer ingress paths for water than competitor?s twin piston caliper, and 1 lb lighter. Manual adjuster stem has 30lb. maximum torque, which is almost twice as high as break point for competitor?s shear nut. |
| FMSI | 1370 |
| Left Or Right | Pair |
| Model | EX225L |
| Mounting Hole Size | M20 X 2.0 |
| New or Reman | New |
| Numbers Of Pistons | 2 |
| OEM | Meritor |
| Pad Length | 8.50 in. |
| Pads Included | Yes |
| Pallet Quantity | 2 |
| Related Core Group | BC605 |
| Related Core Number | XM3056 |
| Related Disc Pad Number | KIT2252L2CG; ED1370S |
| Related Hardware Kit | KIT225270 |
| Weight | 184.00 |
