Name: Reach Cooling 61-1023 Charge Air Cooler
SKU: 611023
Price: 816.99 USD
Availability: InStock

REACH COOLING part description

Product Description

Charge Air Cooler

Application Summary

Peterbilt: 357 1987-1995, 2002; 359 1985-1987; 362 1986-1990; 375 1988-1993; 377, 379 1987-1994; 378 1988-1994

Features & Benefits

Reach charge air coolers are built to withstand the pressures of long hauls. From the product design to the package it is shipped in, every consideration is taken to ensure longevity and peak performance.
Reinforced Aluminum Alloy: Header reinforced with aluminum bronze to increase strength by 50%.
7 Layer Packaging: Each charge air cooler is packaged in a heavy duty, 7 layer corrugated box to ensure best protection during transit.
Header Plate Bond: We use a wider angle header plate bond to eliminate the risk of header cracking.
Deep Extrusion Header: Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion.
Flat Tube Wall Thickness: Flat tube wall thickness is no less than .55mm to maximize ability to withstand added pressure.
Reinforcement Rib: Tubes feature a reinforcing rib to increase material strength.

Product Attributes

Inlet Header Length	691 mm
Core Length	27 IN
Outlet Header Width	67 mm
Inlet Header Width	67 mm
Outlet Location	Upper Right
Core Height	632 MM
Core Thickness	56 MM
Inlet Outside Diameter	4 5/8 IN
Outlet Outside Diameter	118 MM
Inlet Location	Upper Left
Outlet Header Length	27 3/16 in
Core Row Quantity	1
Inlet Header Length	27 3/16 in
Core Material	Aluminum
Outlet Header Length	690.6 mm
Type	Harmonica-shaped tube
Core Thickness	2.187 IN
Outlet Outside Diameter	4.625 IN
Inlet Header Width	2.625 in
Outlet Header Width	2.625 in
Core Height	24.875 IN
Inlet Outside Diameter	117.5 MM
Core Length	686.5 MM

Additional Information

Country of Origin (Primary)	CN
UPC	06949521756130

Part Interchanges

REACH COOLING 61-1023 Cross Reference

We have 140 alternatives for the 61-1023 by REACH COOLING:

Fits Vehicles

Peterbilt 379 (1987-1991, 1993-1994)
Peterbilt 377 (1987-1994)
Peterbilt 362 (1986-1990)
Peterbilt 359 (1985-1987)
Peterbilt 375 (1988-1991, 1993)
Peterbilt 357 (1987-1990, 1992-1995, 2002)
Peterbilt 378 (1988-1994)
