Parker Hannifin 62PLP-4 - Pipe Fitting - Brass

Being the world's leader in push-to-connect fitting technology Parker's Prestolok PLP nickel plated brass fittings provide a simple way of connecting tubes to a fitting in order to create a fluid distribution network. Prestolok PLP metal fittings reduce assembly time by eliminating the use of a sleeve and tightening of a nut required in compression style fittings. Simply push the tubing into the fitting until it bottoms. To disassemble, press the release button, hold against the body and pull tubing from the fitting. A thread sealant is applied to all male threads eliminating the possibility of system contamination from PTFE tape.
Use with the following Parker Parflex Division tubing.
• Polyethylene
• Polypropylene
• Plasticized Nylon
• Unplasticized Nylon
• Polyurethane 90 - 95 Durometer Shore A
• Polyurethane >95 Durometer Shore A

Markets:
• Industrial
• Automotive
• Semi-conductor
• Packaging
• Robotics
• Climate control
• Textile
• Vacuum

Features/benefits:
• Compact one piece fitting
• Swivels on all male threaded shapes for assembly in tight places and for precise positioning
• Pre-applied white acrylic sealant
• NPT, UNF, BSPT, BSPP and Metric threads
• Corrosion resistance
• Push-to-Connect for fast assembly and disassembly
• 1/8" - 1/2", 4mm - 14mm

Applications:
• Air lines
• Inert gases
• Oil lines
• Vacuum lines

Technical Specifications:
• Stainless steel grab ring
• Nitrile seal
• Nickel plated brass body
• Polyacetal release button

Custom configurations and sizes are available upon request. Contact Parker Fluid System Connectors Division at (269) 692-6555 or fscsales@parker.com for additional information.

Specifications

Body Material	Nickel Plated Brass
Minimum Working Temperature (F)	0
Minimum Working Temperature (C)	-18
Maximum Working Temperature (F)	200
Maximum Working Temperature (C)	93
Maximum Working Pressure (psi)	300
Maximum Working Pressure (bar)	20
Tubing Material	Polyethylene, Polypropylene, Nylon, Rigid Nylon, Polyurethane 90-95 Durometer
Seal Material	Nitrile
Gripping Ring	Stainless Steel
Release Button Material	Polyacetal
Thread Type	NPTF, UNF, BSPT, BSPP
Vacuum Rating (inch of Hg)	28
Application	Pneumatics, Packaging, Textile, Semi-conductors, Robotics

PARKER HANNIFIN 62PLP-4 Cross Reference

We have 2 alternatives for the 62PLP-4 by PARKER HANNIFIN:

• TDA3202R9456
• PH62PLP4
