Delphi TC1611 - Ball Joint
$4049
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Ball Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040 |
| Color | Gray |
| Stud Thread Diameter | 16 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 95 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| 3068 | 0.984 IN |
| Mounting Bolt Length | 25.00 MM |
| Washers Included | Yes |
| Height | 4.567 IN |
| Nuts Included | Yes |
| Mounting Hole Quantity | 4 |
| Adjustable | No |
| Greasable | Yes |
| 4966 | 1.142 IN |
| 839 | 11mm |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Dust Boot Material | Rubber |
| Mounting Bolt Shank Diameter | 12.00 MM |
| 9203 | 0.484 IN |
| Mounting Bolt Head Diameter | 12.30 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Threads Per Inch | 28 |
| Mounting Bolt Thread Length | 23.00 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.167 IN |
| 9212 | 0.76 IN |
| Stud Tapered End 2 Diameter | 19.3 MM |
| 9213 | 0.969 IN |
| Stud Tapered End 1 Diameter | 24.6 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 106.00 MM |
| Length | 4.170 IN |
| Stud Thread Diameter | 0.63 IN |
| Height | 116.00 MM |
| Stud Thread Length | 29.01 MM |
| 9202 | 0.470 IN |
| 9207 | 0.910 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604278536 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
Fits Vehicles
- Chevrolet Blazer (1992-1994)
- GMC Yukon (1992-1996)
- GMC Safari (1990-2005)
- GMC K3500 (1988-1995)
- GMC K2500 Suburban (1992-1995)
- GMC K2500 (1988-1995)
- GMC K1500 Suburban (1992-1999)
- GMC K1500 (1988-1995)
- Chevrolet Tahoe (1995)
- Chevrolet K3500 (1988-1995)
- Chevrolet K2500 Suburban (1992-1995)
- Chevrolet K2500 (1988-1995)
- Chevrolet K1500 Suburban (1992-1999)
- Chevrolet K1500 (1988-1995)
- Chevrolet Astro (1990-2005)
