Name: Delphi TA2261 Tie Rod End
SKU: ta2261
Price: 38.49 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Inner, Right Inner. For the position specific to your vehicle, refer to the Applications.
Item Grade	Standard Replacement
Length	704.00 MM
Color	Black
End 1 Gender	Male
End 2 Gender	Male
Pre-Greased	Yes
Grease Fitting Included	Yes
Dust Boot Included	Yes
Width	44 MM
Type	Bent
Mounting Hardware Included	Yes
End 2 Thread Diameter	0.563 IN
Height	90.00 MM
Grade Type	Standard
Housing Material	Steel
Adjustable	No
Greasable	Yes
Weight	7.14 lb
Bearing Material	Plastic
End 1 Thread Direction	Counterclockwise (Left)
End 2 Thread Direction	Clockwise (Right)
Grade	Premium
Stud Type	Threaded
End 1 Thread Pitch	1.5 MM
Length Stud Center to End	682.00 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 2 Threads Per Inch	18
End 1 Thread Diameter	22.00 MM
End 2 Thread Diameter	14.30 MM
Length Stud Center to End	26.850 IN
End 1 Thread Diameter	0.866 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708998175
Harmonized Tariff Code (HTS)	8708998180
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TR
UPC	00689604277423
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Ford Ranger (1983-1988)
Ford Bronco II (1984-1988)
