HALDEX LCP3030HD Part Description
Manufacturer
Product Description
Type 3030, LifeSeal+, 2.5" Stroke, Pushrod 10", HD Housing , Threaded Clevis
Application Summary
3030 LifeSeal+, Stroke 2.5", Pushrod 10.00", Heavy duty housing, High output power spring,Threaded with clevis
Features & Benefits
- Anchorlok® Spring Brake , Model Types 20S and 2024, T-20 Clamp Band Kit
- Anchorlok(R) Spring Brake , Model Types 20S and 2024, T-20 Clamp Band Kit
- Comes with truly sealed double diaphragm to effectively prevent contaminants from reaching the power spring
- Uses standard power spring technology for unparalleled force output consistency
- With heavy-duty housing to withstand impact and extreme conditions
- Engineered smart and road-tested to ensure reliable, durable performance
- Threaded with clevis
Haldex LifeSeal+ Combination Air Brake Spring Brake
Equip your vehicle with a high-quality Haldex LifeSeal+ combination air brake spring brake. This product is the only truly sealed double diaphragm spring brake specifically designed for heavy duty applications.
HALDEX LCP3030HD Specifications
Product Attributes
| Air Port Position | 90° |
| Bracket to End of Spring Housing Length | 8.95 in. |
| Freight Class | 70 |
| Piggyback Length | 6.42 in. |
| Push Rod Diameter | 5/8 in. |
| Push Rod Length | 10 in. |
| Series | LifeSeal+ |
| Service Chamber Size | 30/30 |
| Service Clampband Position | 0° |
| Service Clampband Size | 10.18 in. |
| Spring Housing Flange Size | 8.19 in. |
| Stroke Length | 2.5 in. |
| Stroke Type | Standard |
| Stud Distance | 4.75 in. |
| Dimension At Rolled Spring Housing Flange | 8.19 |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412310080 |
| Harmonized Tariff Code (HTS) | 8412310080 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| Core Group | - |
| UPC | 00767653370828 |
| VMRS Code | 013004027 |
HALDEX LCP3030HD Cross References
HALDEX LCP3030HD Customer Reviews
No reviews yet
Be the first to review this product!
HALDEX LCP3030HD Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
