Delphi TC1607 - Ball Joint
$4199
MSRP: $59.58
Save: $17.59
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 1.890 IN |
| Maximum Outside Diameter | 48.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.551 IN |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 96 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| 3068 | 1.587 IN |
| Mounting Bolt Length | 40.30 MM |
| Washers Included | No |
| Height | 4.528 IN |
| Height | 115.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 4 |
| Adjustable | No |
| Greasable | Yes |
| 4966 | 0.803 IN |
| Stud Thread Length | 20.4 MM |
| 839 | 11mm |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 27.00 MM |
| Dust Boot Material | Rubber |
| 9202 | 0.315 IN |
| Mounting Bolt Shank Diameter | 8.00 MM |
| 9203 | 0.567 IN |
| Mounting Bolt Head Diameter | 14.40 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.25 MM |
| 9207 | 1.299 IN |
| Mounting Bolt Thread Length | 33.00 MM |
| Mounting Bolt Thread Diameter | 8.00 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| 9212 | 0.787 IN |
| Stud Tapered End 2 Diameter | 20 MM |
| 9213 | 0.587 IN |
| Stud Tapered End 1 Diameter | 14.9 MM |
| Stud Thread Pitch | 1.5 MM |
| Mounting Bolt Thread Diameter | 0.310 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604278574 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
Fits Vehicles
- Ford LTD Crown Victoria (1987-1991)
- Mercury Zephyr (1978-1983)
- Mercury Marquis (1979-1986)
- Mercury Cougar (1980-1988)
- Mercury Grand Marquis (1979-1994)
- Mercury Colony Park (1987-1991)
- Mercury Capri (1979-1986)
- Lincoln Town Car (1981-1994)
- Lincoln Mark VI (1980-1983)
- Ford Thunderbird (1980-1988)
- Ford Mustang (1979-1993)
- Ford Granada (1981-1982)
- Ford Fairmont (1978-1983)
- Ford Crown Victoria (1992-1994)
- Ford LTD (1979-1986)
- Ford Country Squire (1987-1991)
- Ford Aerostar (1986-1997)
