DELPHI TA2246 Part Description
DELPHI TA2246 Specifications
Product Attributes
| Position(s) | Outer |
| Item Grade | Standard Replacement |
| Color | Gray |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Dust Boot Included | Yes |
| Width | 39.5 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.625 IN |
| End 2 Thread Diameter | 15.88 MM |
| Height | 77.80 MM |
| Housing Material | Steel |
| Tube Diameter | 0.625 IN |
| Tube Diameter | 15.88 MM |
| Adjustable | No |
| Weight | 0.77 lb |
| Cone Outside Diameter | 14.40 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Counterclockwise (Left) |
| Stud Type | Threaded |
| Length - Stud Center to End | 4.055 IN |
| Length - Stud Center to End | 103.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 2 Threads Per Inch | 18 |
| End 1 Threads Per Inch | 20 |
| End 1 Thread Diameter | 0.437 IN |
| End 1 Thread Diameter | 11.11 MM |
| Shank Length | 14.40 MM |
| Stud Length | 14.40 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.567 IN |
| Stud Length | 0.567 IN |
| Cone Outside Diameter | 0.567 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604277539 |
| VMRS Code | 015004045 |
| UNSPSC | 25174205 |
DELPHI TA2246 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | ES368RL |
| Mevotech | MES368RL |
| Chrysler | J3205502, J3215775 |
| MAS Industries | T368 |
| N/A | GES368RL, T368PR |
DELPHI TA2246 Fits Vehicles
- American Motors Rebel (1970)
- American Motors Rambler (1969)
- American Motors Javelin (1968-1974)
- American Motors Rogue (1966)
- American Motors American (1964-1968)
- American Motors Ambassador (1970-1974)
- American Motors Spirit (1979-1983)
- American Motors Matador (1971-1977)
- American Motors Gremlin (1970-1978)
- American Motors Hornet (1971-1977)
- American Motors Concord (1978-1983)
- American Motors AMX (1968-1970, 1978-1980)
