Delphi TC2190 - Control Arm and Ball Joint Assembly
$17249
MSRP: $241.83
Save: $69.34
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Control Arm and Ball Joint Assembly
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Adjustable | No |
| Greasable | No |
| Control Arm Maximum Width | 4.331 IN |
| Control Arm Maximum Width | 110.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Stud Length | 0.965 IN |
| Ball Joint Stud Length | 24.50 MM |
| Control Arm Maximum Length | 18.417 IN |
| Control Arm Maximum Length | 467.80 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.551 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604256084 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
Part Interchanges
- Beck/Arnley 101-6146
- Beck/Arnley 102-6146
- MOOG Chassis Products K620153
- MOOG Chassis Products RK620153
- Mevotech CMS70102
- Mevotech MS70101
- Mevotech MS70102
- Audi 7L0 407 152 E
- Audi 7L0 407 152 H
- Audi 955 341 018 30
- Porsche 955 341 018 30
- Porsche 955 341 018 32
- Porsche 955 341 018 33
- Volkswagen 7L0 407 152 E
- Volkswagen 7L0 407 152 H
- Volkswagen 7L0 407 152C
- MAS Industries CB43004
- MAS Industries CB43004PR
- TRW JTC1058
- Dorman 520-972
- MOOG Chassis Products 102-6146
- JTC1184
- 52-1955
- GS70102
Fits Vehicles
- Volkswagen Touareg (2004-2010)
- Porsche Cayenne (2003-2006, 2008-2010)
