(888) 312-8812 Login SignupDELPHI TC1748 Control Arm and Ball Joint Assembly
Tap to view 2 more
MSRP: $265.95
$21599
Save $49.96
Limited availability at this price!
In Stock
Get it by Monday, Dec 22
DELPHI TC1748 Part Description
DELPHI TC1748 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Bolt In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 15.354 IN |
| Control Arm Maximum Width | 390.00 MM |
| Control Arm Color | Black |
| Ball Joint Stud Length | 3.543 IN |
| Ball Joint Stud Length | 90.00 MM |
| Control Arm Maximum Length | 16.732 IN |
| Control Arm Maximum Length | 425.00 MM |
| Mounting Hole Diameter | 0.709 IN |
| Mounting Hole Diameter | 18.00 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604253625 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC1748 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5459, 102-5459 |
| MOOG Chassis Products | K620515, RK620515 |
| Mevotech | CMS90105 |
| Deeza | KI-H204 |
| Kia | 54520-3E001 |
| MAS Industries | CB63134, CB63134PR |
DELPHI TC1748 Fits Vehicles
- Kia Sorento (2003-2006)
