(888) 312-8812 Login SignupDELPHI TC1299 Ball Joint
Tap to view 14 more
MSRP: $26.25
$2249
Save $3.76
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
DELPHI TC1299 Part Description
DELPHI TC1299 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 2.559 IN |
| Maximum Outside Diameter | 65.00 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 65 MM |
| Type | Premium |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 1.693 IN |
| Height | 43.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.807 IN |
| Stud Thread Length | 20.5 MM |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Bushing Quantity | 0 |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.63 IN |
| Stud Tapered End 2 Diameter | 16 MM |
| Stud Tapered End 1 Diameter | 0.709 IN |
| Stud Tapered End 1 Diameter | 18 MM |
| Stud Thread Pitch | 1.25 MM |
| Length | 85.00 MM |
| Length | 3.350 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604251652 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1299 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-5477, 101-6825 |
| Raybestos Chassis | 505-1310 |
| MOOG Chassis Products | K90332 |
| Mcquay-Norris | FA2213 |
| Mevotech | MK90332 |
| Deeza | HN-G614 |
| Honda | 51220-S5A-003, 51220-S5A-J10, 51220-S5A-J30 |
| MAS Industries | B90332, BJ59435 |
| TRW | JBJ491 |
| Import Direct | BJ06002 |
| N/A | GK90332, TXK90332 |
DELPHI TC1299 Fits Vehicles
- Acura EL (2001-2005)
- Honda Civic (2001-2005)
