Delphi TC1235 - Ball Joint
$1899
MSRP: $30.28
Save: $11.29
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 4.606 IN |
| Maximum Outside Diameter | 117.00 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 117 MM |
| Type | Premium |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 2.008 IN |
| Height | 51.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greasable | No |
| 4966 | 0.748 IN |
| Stud Thread Length | 19 MM |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 90.00 MM |
| Dust Boot Material | Rubber |
| Bushing Quantity | 0 |
| Mounting Bolt Shank Diameter | 12.20 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| 9212 | 0.709 IN |
| Stud Tapered End 2 Diameter | 18 MM |
| 9213 | 0.811 IN |
| Stud Tapered End 1 Diameter | 20.6 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 117.00 MM |
| Length | 4.610 IN |
| 9202 | 0.480 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604251386 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
- Beck/Arnley 101-5125
- Raybestos Chassis 505-1351
- MOOG Chassis Products K80621
- Mcquay-Norris FA2280
- Mevotech MK80621
- Mevotech MK90374
- Deeza HU-G206
- Kia 51760-38000
- Hyundai 51760-38000
- MAS Industries BJ60015
- MAS Industries BJ60125
- MAS Industries BJ63055
- TRW JBJ7555
- Import Direct BJ07002
- Import Direct BJ14064
- Import Direct BJ14071
- Dorman BJ60015
- GK80621
Fits Vehicles
- Kia Magentis (2001-2006)
- Kia Amanti (2004-2006)
- Kia Optima (2001-2006)
- Hyundai XG350 (2002-2005)
- Hyundai XG300 (2001)
- Hyundai Sonata (1999-2005)
