Name: Delphi TA2916 Tie Rod End
SKU: ta2916
Price: 35.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Right Outer
Item Grade	Standard Replacement
Color	Black
End 2 Gender	Female
Pre-Greased	Yes
Grease Fitting Included	No
Dust Boot Included	Yes
Width	63.8 MM
Type	Bent
Mounting Hardware Included	Yes
End 2 Thread Diameter	0.630 IN
End 2 Thread Diameter	16.00 MM
Height	92.50 MM
Housing Material	Steel
36	0.886 IN
Tube Diameter	22.50 MM
Adjustable	No
Greasable	No
Weight	1.82 lb
Cone Outside Diameter	19.00 MM
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Stud Type	Threaded
End 2 Thread Pitch	1.5 MM
Length Stud Center to End	8.150 IN
Length Stud Center to End	207.00 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 1 Thread Diameter	0.472 IN
End 1 Thread Diameter	12.00 MM
Shank Length	19.00 MM
Stud Length	19.00 MM
Grade Type	Standard
Grade	Premium
Shank Length	0.748 IN
Stud Length	0.748 IN
662	0.748 IN

Additional Information

Harmonized Tariff Code (HTS)	8708998180
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Harmonized Tariff Code (Schedule B)	8708998175
Country of Origin (Primary)	TR
UPC	00689604249550
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Porsche Macan (2015-2022)
Audi A4 allroad (2013-2016)
Audi allroad (2013-2016)
Audi SQ5 (2014-2017)
Audi RS7 (2014-2018)
Audi RS5 (2013-2015)
Audi S6 (2013-2018)
Audi S7 (2013-2018)
Audi S4 (2013-2015)
Audi A4 Quattro (2013-2015)
Audi A4 (2013-2015)
Audi A6 (2012-2018)
Audi S5 (2012-2017)
Audi A6 Quattro (2012-2018)
Audi A5 Quattro (2012-2017)
Audi A5 (2012-2014)
Audi A7 Quattro (2012-2014, 2016-2018)
Audi Q5 (2009-2017)
