Name: Delphi TA2786 Tie Rod End
SKU: ta2786
Price: 35.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Left Outer
Item Grade	Standard Replacement
Color	Black
End 2 Gender	Female
Pre-Greased	Yes
Grease Fitting Included	No
Dust Boot Included	Yes
Width	59.5 MM
Type	Bent
Mounting Hardware Included	Yes
End 2 Thread Diameter	14.00 MM
End 2 Thread Diameter	0.551 IN
Height	76.40 MM
Housing Material	Steel
Tube Diameter	24.50 MM
36	0.965 IN
Adjustable	No
Greasable	No
Weight	2.17 lb
Cone Outside Diameter	18.58 MM
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Stud Type	Threaded
End 2 Thread Pitch	1.5 MM
Length Stud Center to End	7.780 IN
Length Stud Center to End	197.60 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 1 Thread Diameter	0.551 IN
End 1 Thread Diameter	14.00 MM
Shank Length	18.58 MM
Stud Length	18.58 MM
Grade Type	Standard
Grade	Premium
Shank Length	0.731 IN
Stud Length	0.731 IN
662	0.731 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708998175
Country of Origin (Primary)	TR
Harmonized Tariff Code (HTS)	8708998180
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
UPC	00689604249291
VMRS Code	015004020
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Mercedes-Benz C350 (2006-2007)
Mercedes-Benz C280 (2006-2007)
Mercedes-Benz C320 (2003-2005)
Mercedes-Benz C240 (2003-2005)
