DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s) Outer
Item Grade Standard Replacement
Color Gray
End 1 Gender Female
End 2 Gender Female
Pre-Greased Yes
Grease Fitting Included No
Dust Boot Included Yes
Width 44 MM
Type Straight
Mounting Hardware Included Yes
End 2 Thread Diameter 0.630 IN
End 2 Thread Diameter 16.00 MM
Height 78.50 MM
Housing Material Steel
36 0.689 IN
Tube Diameter 17.50 MM
Adjustable No
Greasable No
Weight 1.6 lb
662 0.906 IN
Cone Outside Diameter 23.00 MM
Bearing Material Plastic
End 1 Thread Direction Clockwise (Right)
End 2 Thread Direction Clockwise (Right)
Stud Type Threaded
End 2 Thread Pitch 1.5 MM
Length Stud Center to End 6.299 IN
Length Stud Center to End 160.00 MM
Dust Boot Material Rubber
Tie Rod Material Steel
End 1 Thread Diameter 0.315 IN
End 1 Thread Diameter 8.00 MM
Shank Length 23.00 MM
Stud Length 23.00 MM
Grade Type Standard
Boot Color Black
Grade Premium
Shank Length 0.906 IN
Stud Length 0.906 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708998175
Country of Origin (Primary) TR
Harmonized Tariff Code (HTS) 8708998180
Warranty Special Limited Lifetime
Warranty Special UOM LF
UPC 00689604247846
VMRS Code 015004045
UNSPSC 25174205

Part Interchanges

Fits Vehicles

  • Volkswagen Phaeton (2004-2006)
  • Audi S8 (2003, 2007-2009)
  • Audi A8 Quattro (2003-2010)
