DELPHI part description

Product Description

Fuel Transfer Unit

Product Attributes

Item Grade Standard Replacement
Fuel Level Sender Assembly Included Yes
Package Contents Fuel Transfer Unit w/Float Arm, Seal, Instruction Sheet
Vapor Pressure Sensor No
Outlet Outside Diameter 0.375 IN
Fuel Type Diesel
Regulator Included No
Terminal Type Blade
Gasket Or Seal Included Yes
Terminal Quantity 4
Terminal Gender Male
Strainer Included No
Inlet Type Quick Connect
Outlet Type Quick Connect
Outlet Quantity 4
In Tank or External In Tank
Resistance Ohms Empty 250.0 82
Resistance Ohms Full 40.0 82
Internal Or External Strainer Internal
Inlet Outside Diameter 7.9 MM
Suction Pipe Included No
Connector Shape Oval
Housing Material Plastic
Connector Gender Female
Fuel Tank Pressure Sensor Included No
Outlet Outside Diameter 9.5 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8413309000
Warranty Special Limited Lifetime
Warranty Special UOM LF
Harmonized Tariff Code (HTS) 8413309030
Country of Origin (Primary) CN
UPC 00689604271711
VMRS Code 044001089
UNSPSC 25172411

Part Interchanges

Fits Vehicles

  • GMC Sierra 2500 HD (2008-2010)
  • GMC Sierra 3500 HD (2008-2010)
  • Chevrolet Silverado 2500 HD (2008-2010)
  • Chevrolet Silverado 3500 HD (2008-2010)
