CENTRIC 320.67045 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.67045 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.140 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 15.700 |
| Discard Thickness | 22.700 MM |
| Discard Thickness | 0.894 IN |
| Nominal Thickness | 24.000 MM |
| Nominal Thickness | 0.945 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 78.000 MM |
| Overall Height | 3.071 IN |
| Outside Diameter | 11.024 IN |
| Outside Diameter | 280.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.835 IN |
| Center Hole Diameter | 72.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.000 MM |
| Stud/Lug Hole Diameter | 0.630 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590253238 |
CENTRIC 320.67045 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 76923, 76923FZN, 76923R |
| N/A | 90042026 |
CENTRIC 320.67045 Cross References
We have 3 alternatives for the 320.67045 by CENTRIC:
