Centric 320.66059 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Misc Holes [cntrc] | 2 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 13.480 |
| Vane Style [cntrc] | Straight |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 29.650 |
| Discard Thickness | 1.437 IN |
| Discard Thickness | 36.500 MM |
| Nominal Thickness | 37.800 MM |
| Nominal Thickness | 1.488 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 89.300 MM |
| Overall Height | 3.516 IN |
| Outside Diameter | 324.600 MM |
| Outside Diameter | 12.780 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.654 IN |
| Center Hole Diameter | 118.200 MM |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 16.400 MM |
| Stud/Lug Hole Diameter | 0.646 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590253078 |
Part Interchanges
CENTRIC 320.66059 Cross Reference
We have 3 alternatives for the 320.66059 by CENTRIC:
