Centric 320.66056 - Centric GCX Rotor with Partial Coating
$4999
MSRP: $52.78
Save: $2.79
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 6.820 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Behind the Hub |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 15.000 |
| Discard Thickness | 1.008 IN |
| Discard Thickness | 25.600 MM |
| Nominal Thickness | 26.900 MM |
| Nominal Thickness | 1.059 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 39.900 MM |
| Overall Height | 1.571 IN |
| Outside Diameter | 11.024 IN |
| Outside Diameter | 280.000 MM |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.250 MM |
| Bearings Included | No |
| Center Hole Diameter | 3.626 IN |
| Center Hole Diameter | 92.100 MM |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 12.000 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590253054 |
Part Interchanges
CENTRIC 320.66056 Cross Reference
We have 3 alternatives for the 320.66056 by CENTRIC:
