Centric 320.65085 - Centric GCX Rotor with Partial Coating
$5299
MSRP: $72.90
Save: $19.91
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Weight [cntrc] Lbs | 19.000 |
| Weight [cntrc] Kgs | 8.640 |
| Max Pb Drum Dia [cntrc] Mm | 230.000 |
| Max Pb Drum Dia [cntrc] In | 9.055 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 12.000 MM |
| Discard Thickness | 0.472 IN |
| Nominal Thickness | 14.200 MM |
| Nominal Thickness | 0.559 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 56.300 MM |
| Overall Height | 2.217 IN |
| Outside Diameter | 334.000 MM |
| Outside Diameter | 13.150 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 228.400 MM |
| Nominal Drum Diameter | 8.992 IN |
| Bearings Included | No |
| Center Hole Diameter | 3.445 IN |
| Center Hole Diameter | 87.500 MM |
| Mounting Bolt Hole Circle Diameter | 135.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.000 MM |
| Stud/Lug Hole Diameter | 0.630 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590252644 |
Part Interchanges
CENTRIC 320.65085 Cross Reference
We have 3 alternatives for the 320.65085 by CENTRIC:
