Centric 320.63062 - Centric GCX Rotor with Partial Coating
$6399
MSRP: $67.17
Save: $3.18
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Hat Id [cntrc] In | 6.154 |
| Weight [cntrc] Kgs | 8.180 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 18.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Hat Id [cntrc] Mm | 156.300 |
| Max Pb Drum Dia [cntrc] Mm | 185.500 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 0.807 IN |
| Discard Thickness | 20.500 MM |
| Nominal Thickness | 22.000 MM |
| Nominal Thickness | 0.866 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 67.400 MM |
| Overall Height | 2.654 IN |
| Outside Diameter | 320.000 MM |
| Outside Diameter | 12.598 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 183.900 MM |
| Nominal Drum Diameter | 7.240 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.858 IN |
| Center Hole Diameter | 72.600 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.700 MM |
| Stud/Lug Hole Diameter | 0.657 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590252446 |
Part Interchanges
CENTRIC 320.63062 Cross Reference
We have 6 alternatives for the 320.63062 by CENTRIC:
