CENTRIC 320.51039 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.51039 Specifications
Product Attributes
| Hat Id [cntrc] Mm | 189.900 |
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 3 |
| Hat Id [cntrc] In | 7.476 |
| Weight [cntrc] Lbs | 13.650 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 191.000 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] In | 7.520 |
| Weight [cntrc] Kgs | 6.200 |
| Discard Thickness | 0.370 IN |
| Discard Thickness | 9.400 MM |
| Nominal Thickness | 0.433 IN |
| Nominal Thickness | 11.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 71.500 MM |
| Overall Height | 2.815 IN |
| Outside Diameter | 11.894 IN |
| Outside Diameter | 302.100 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 189.800 MM |
| Nominal Drum Diameter | 7.472 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.500 MM |
| Stud/Lug Hole Diameter | 0.492 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590251791 |
