(888) 312-8812 Login SignupDELPHI FG1899 Fuel Pump Module Assembly
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI FG1899 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1899 Specifications
Product Attributes
| Outlet Outside Diameter | 0.313 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 75.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 479.0 82 |
| Resistance Ohms Full | 20.0 82 |
| Internal Or External Strainer | Internal |
| Average Current Draw | 8 68 |
| Average Flow Rating | 26 GPH |
| Pump Type | Electric |
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| System Pressure | 70 psi |
| Vapor Pressure Sensor | No |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Remanufactured Part | N |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604265116 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1899 Part Interchanges
| Brand | Part Number |
|---|---|
| AutoZone | CFG1899 |
| BMW | 16 11 9 807 103, 16 11 9 810 569 |
| Airtex | E9167M |
