(888) 312-8812 Login SignupWABCO 4235100460 Air Brake Chamber - Unistop Series, Disc Brakes
Tap to view 3 more
$20849
14 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4235100460 Part Description
WABCO 4235100460 Specifications
Product Attributes
| Type | 22 |
| Temperature Range | -40°C to +80°C |
| Stroke | 65.0 mm |
| Push-rod thread | Ball R8 |
| Return-Spring Force | 190 N |
| Max. operating pressure | 10.2 bar |
| Type Of Operation | Disc |
| Port threads | 3/8" - 18 NPTF |
| Weight | 0.0022046 |
| Version | Without boot |
| Total Length | 121.0 mm |
| Distance between bolts | 120.6 mm |
| Push-Rod Length | 15 mm |
| Bolt Lengths | 38.5 mm |
| Bolt Threads | M16 x 1.5 |
WABCO 4235100460 Cross References
| Brand | Part Number |
|---|---|
| MACK | 21897411 |
| MERITOR | 4235100460, S4235100460 |
| VOLVO | 21897411 |
WABCO 4235100460 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4235100460 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
