(888) 312-8812 Login SignupRAYBESTOS 780928FZN Raybestos Element3 Coated Brake Rotor
$6999
Limited availability at this price!
In Stock
Get it by Monday, Feb 9
RAYBESTOS 780928FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2013-2009 Dodge Journey Front, 2011-2010 Chrysler Town & Country Front, 2014-2011 Volkswagen Routan Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 780928FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.85 IN |
| Center Hole Diameter | 72.4 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.039 IN |
| Discard Thickness | 26.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.701 IN |
| Inside Diameter | 195.6 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.546 IN |
| Mounting Bolt Hole Diameter | 13.85 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.89 IN |
| Outside Diameter | 302 MM |
| Overall Height | 1.5 IN |
| Overall Height | 38.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213142990 |
RAYBESTOS 780928FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | N1000415074WBR |
| BRAKEBEST | 780928, 780928FZN, 780928PER, 780928R, 780928RGS |
| CENTRIC | 320.67069 |
| CHRYSLER | 4721995AB, 68032944AA, 68032944AB |
| Centric Parts | 120.67069, 121.67069 |
| DURA CORP | BR53065, BR900524-02 |
| DuraGo | 900524, BR900524, BR90052402, BR900524-02 |
| NEWTEK AUTOMOTIVE | 53065 |
| Newtek Automotive USA | 53065 |
| Qualis | 43166 |
| TopNotch | TN780928GEO |
| VOLKSWAGEN | 7B0615301D, 7B0615301, 7B0615301B, 7B0615301C |
| WAGNER BRAKE | BD180353, BD180464E |
RAYBESTOS 780928FZN Fits Vehicles
- Ram C/V (2012-2015)
- Dodge Grand Caravan (2008-2016)
- Volkswagen Routan (2009-2014)
- Chrysler Town & Country (2008-2016)
- Dodge Journey (2009-2013)
