*Representative image - actual part not displayed
Centric 120.62174 - Centric Premium Brake Rotor
$9049
MSRP: $110.53
Save: $20.04
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 6 |
| Hat Id [cntrc] Mm | 159.800 |
| Hat Id [cntrc] In | 6.291 |
| Weight [cntrc] Kgs | 11.700 |
| Weight [cntrc] Lbs | 25.750 |
| OEM Vane Count [cntrc] | 51 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.063 IN |
| Discard Thickness | 27.000 MM |
| Nominal Thickness | 30.000 MM |
| Nominal Thickness | 1.181 IN |
| Hat Finish | Coated |
| Overall Height | 51.100 MM |
| Overall Height | 2.012 IN |
| Outside Diameter | 345.000 MM |
| Outside Diameter | 13.583 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 67.500 MM |
| Center Hole Diameter | 2.657 IN |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 15.700 MM |
| Stud/Lug Hole Diameter | 0.618 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590182873 |
Part Interchanges
CENTRIC 120.62174 Cross Reference
We have 3 alternatives for the 120.62174 by CENTRIC:
Fits Vehicles
- Cadillac XT6 (2020-2023)
- Cadillac XT5 (2017-2023)
- Buick Enclave (2018-2020)
