(888) 312-8812 Login SignupWEATHERHEAD EC810-24 Hydraulic Hose - Black, Synthetic Rubber, 1.5" I.D, 2.29" O.D, 6100 psi
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WEATHERHEAD EC810-24 Part Description
Manufacturer
| Abrasion Resistance | Premium |
| Application | Hydraulic system with Petroleum based fluids for low temperature application |
| Burst Pressure | 24360 psi |
| Certifications | SAE 100R15 |
| Color | Black |
| Compliances | MSHA Approved |
| Conductivity | Conductive |
| Construction | 6 Spiral |
| Cover Material | Synthetic Rubber |
| Dash Size | -24 |
| Description Product Name | Eaton EC810 Series Hose Spiral |
| Description Short | Hose |
| ECCN | EAR99 |
| ICC | Hoses and Flexible Tubes |
| Impulse Cycle Life | 500000 cycle |
| Inside Diameter | 1.5 inch |
| Inside Diameter UNSPSC | inch |
| Lay Line Style | Ink Transfer |
| Lead Time | 7 |
| List price | 187.18 |
| Maximum Pressure UNSPSC | psi |
| Maximum Working Temperature | 212 degree Fahrenheit |
| Minimum Bend Radius | 20.08 inch |
| Minimum Working Temperature | -70 degree Fahrenheit |
| NMFC | 70 |
| Net Pack Quantity | 1 |
| Net Pack Quantity Units | FT |
| Outside Diameter | 2.29 inch |
| Outside Diameter UNSPSC | inch |
| Package Form | Bulk |
| Part Status | AC |
| Product Trade Name | EC810 Series |
| Qualified Hose Fittings | 4S,6S |
| Reinforcement Material | Wire |
| Segment Code | A |
| Tube Material | Synthetic Rubber |
| Tube Wall Thickness | 0.38 inch |
| UNSPSC | 40142020 |
| Working Pressure | 6100 psi |
Features & Benefits
- Rugged, spiral hose offers top performance in frigid temperatures.
- Cover is MSHA qualified to use in mining applications.
- Performs at highest hydraulic pressures typically seen in general hydraulic applications.
- Easy to assemble.
- Abrasion resistant cover.
- Proven, reliable hose and fitting technology.
WEATHERHEAD EC810-24 Customer Reviews
No reviews yet
Be the first to review this product!
WEATHERHEAD EC810-24 Manufacturer Information
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
