Name: Sealed Power L-2268NF 30 "Speed Pro" POWERFORGED Engine Piston Set
SKU: l2268nf30
Price: 923.92 USD
Availability: InStock

SEALED POWER part description

Product Description

Engine Piston Set

Application Summary

1966-1969 Chevrolet Biscayne; 1969 Chevrolet Brookwood; 1969 Chevrolet Kingswood; 1969 Chevrolet Townsman; 1969 Chevrolet Estate; 1966-1969 Chevrolet Bel Air; 1969 Chevrolet Camaro; 1966-1969 Chevrolet Caprice; 1966-1969 Chevrolet Corvette; 1966-1969 Chevrolet Impala; 1966-1969 Pontiac Laurentian; 1966-1969 Pontiac Strato-Chief; 1966-1969 Pontiac Parisienne

Features & Benefits

Forged under 3,000 tons of force.
Fully updated skirt profiles
Exclusive DUROSHIELD(R) skirt coating. DUROSHIELD(R) provides scuff resistance, reduced bore clearances and enhanced ring sealing.
SPEED-PRO(R) POWERFORGED(R) pistons are built to stringent specifications with a precision CNC-machined dome and skirts and microfinished ring grooves.
The manufacturing process ensures that piston weights within a boxed set will not vary more than 4 grams and that skirt sizes are matched to within 0.016mm (0.0006") per set.
Machined valve reliefs and circlip grooves; LR-63 lock rings for floated applications

Product Attributes

Oversized	Yes
Top Compression Ring Thickness	0.0781 IN
Second Compression Ring Thickness	0.0781 IN
Oil Ring Thickness	0.1875 IN
Assembly Lubricant Included	No
Bore Diameter	4.280 IN
Piston Material	POWERFORGED(R)
9607	1.765 IN
Dome Volume CC	35.5
Head Type	.266 dome; DUROSHIELD skirt coated piston; 60 O/S has .255 dome
Lock Ring	N/R
Minimum Clearance	.0035
Oversize Inch	.030
Part Description	Engine Piston
Pin Diameter (Inch)	0.990
Pin Type	P
Pin Weight Gram	154
Weight W Pin Gram	859
Weight w/o Pin Gram	705

Additional Information

Country of Origin (Primary)	IN
Canadian Harmonizing Tariff Code	8409910010
Harmonized Tariff Code (HTS)	8409999190
UPC	00019826077608

Speed-Pro® is the go-to brand not only for racers and performance enthusiasts but also for those who are cruising down the road day in day out. With its engineering expertise, advanced technologies, and industry-leading manufacturing facilities and techniques, Speed-Pro sets the bar higher for other manufacturers of pistons, engine bearing parts, and performance engine components. The engine solutions from Speed-Pro are meticulously designed and crafted to boost horsepower production and make engine rebuild an easy feat. Since its establishment, this brand has continuously improved and refined its operations and quality control measures to maintain high quality standards and satisfy customers’ requirements and demands.

Fits Vehicles

Chevrolet Estate (1969)
Pontiac Laurentian (1966-1969)
Pontiac Parisienne (1966-1969)
Pontiac Strato-Chief (1966-1969)
Chevrolet Townsman (1969)
Chevrolet Kingswood (1969)
Chevrolet Impala (1966-1969)
Chevrolet Corvette (1966-1969)
Chevrolet Camaro (1969)
Chevrolet Caprice (1966-1969)
Chevrolet Brookwood (1969)
Chevrolet Biscayne (1966-1969)
Chevrolet Bel Air (1966-1969)
