Parker Hannifin 30182-2-4B - Push On Field Attachable Hydraulic Hose Fitting - 82 Series Fittings

Parker's 82 series fittings are a one-piece push on field attachable barb style fitting which enables you to quickly and easily make hose assemblies right on the job site without special tools.

Parker's 82 series fittings are a one-piece push on field attachable barb style fitting which enables you to quickly and easily make hose assemblies right on the job site without special tools. The fitting series when coupled with Parker's No-Skive hose provides convenience and shorter assembly time. The 82 series fittings are compatible with push-lok multipurpose hoses including; high temperature, dry air, hot water, fire resistant and higher pressure hoses. The 82 series fittings are available from ¼” to 1” in a wide variety of end configurations.

Markets:
• Construction
• Utility Equipment
• Machine Tool
• Ground Support Equipment
• Industrial
• Automotive

Features/Benefits:
• Can be assembled in field with wrenches
• Imperial HEX
• Wide range of end configurations
• One piece reduces complexity and leakage path
• No-Skive technology offers easy, efficient, and safe production processes

Applications:
• Petroleum base hydraulic fluids and lubricating oils
• Pneumatic
• Antifreeze solutions
• Diesel fuels
• Phosphate ester
• Dry air and water

Compatible Hoses:
• 801
• 804
• 821
• 821FR
• 836

Product Specifcations

PARKER HANNIFIN 30182-2-4B Cross Reference

We have 2 alternatives for the 30182-2-4B by PARKER HANNIFIN:

• HAMZ8005AC
• PH3018224B
