Parker Hannifin 16826-4-4 - Hydraulic Coupling / Adapter

Parker's 26 series fittings are cost effective, permanent, compression style fittings made for easy and quick assembly using our family of Parkrimp crimpers. The fitting series when coupled with Parker's No-Skive hose provides convenience and shorter assembly time. The 26 series fittings are compatible with transportation air brake, compressed natural gas & liquefied petroleum, marine fuel & engine and refrigerant hose. The 26 series fittings are available from 3/16” to 1-13/16” in a wide variety of end configurations.

Markets:
• Transportation
• Military
• Agriculture
• Material Handling
• Marine

Features/Benefits:
• Easy push on force
• Imperial HEX
• Brass option available
• Wide range of end configurations
• One piece reduces complexity and leakage path
• No-Skive technology offers easy, efficient, and safe production processes

Applications:
• Petroleum base hydraulic fluids and lubricating oils
• Diesel fuels
• Antifreeze solutions
• Gasoline
• Ethanol blends
• Air brake systems
• Refrigerant

Compatible Hoses:
• 201
• 206
• 213
• 221FR
• 244
• 266
• 285
• 293
• SS23CG

Specifications

Connection Thread Size (inch)	7/16x20
Port Connection (inch)	1/4
Hose I.D. (size)	-4
Hose I.D. (inch)	3/16
Style	Female JIC 37°/SAE 45° Dual Flare - Swivel
Hose I.D. (mm)	4,8
Shape	Straight
Material	Steel

PARKER HANNIFIN 16826-4-4 Cross Reference

We have 2 alternatives for the 16826-4-4 by PARKER HANNIFIN:

• TBB22010377
• PH1682644
