Parker Hannifin 249F-8-8 - Pipe Fitting - Brass

Parker's 45° flare fittings are economical for a metal-to-metal seal that are designed for high pressure service and have exceptional resistance to mechanical pull out. The positive nature of the connection with the flare on the tube clamped between the nut and the body makes for extreme dependability and safety. Flare fittings are appropriate alternatives for solder type joints where an open flame is either not desired or impractical. Fittings are available in forgings for refrigeration applications. Fittings meet functional requirements of SAE J512 and J513.

Markets:
• Refrigeration
• Heavy Duty Truck
• Mobile
• Industrial
• Heating
• Air conditioning

Features/Benefits:
• All brass construction
• Forged nuts for refrigeration applications
• Long nuts for vibration
• U.L. listed for flammable liquids
• Functional requirements of SAE J512 & SAE J513
• Economical
• Metal-to-metal seal
• Use with copper, brass, aluminum and welded steel hydraulic tubing that can be flared

Applications:
• Refrigerant lines
• Propane lines
• Fuels
• Natural Gas
• Oil burners
• Adapters

Specifications

Minimum Working Temperature (F)	-65
Minimum Working Temperature (C)	-53
Maximum Working Temperature (F)	250
Maximum Working Temperature (C)	121
Maximum Working Pressure (psi)	2800
Maximum Working Pressure (bar)	193
Tubing Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Application	Pumps, Gas Grills, Coffee Makers, Adapters
Industry Standards	SAE J512, SAE J513
Body Material	Brass
Nut Material	Brass
O-Ring	Fluorocarbon

PARKER HANNIFIN 249F-8-8 Cross Reference

We have 2 alternatives for the 249F-8-8 by PARKER HANNIFIN:

• TDA3133E8403
• PH249F88
