Name: Parker Hannifin 4010-6P Hydraulic Coupling / Adapter - Steel
SKU: 40106p
Price: 50.49 USD
Availability: InStock

PARKER HANNIFIN part description

4010 Series Nipples (hydraulic) 3000 psi, connect with 4000 Series Couplers (1/4",3/8", 3/4", 1" sizes) and 4200 Series (3/8" size) couplers. Nipples are available with a poppet or ball valve.

Technical Characteristics:
• Sizes: 1/4", 3/8", 3/4", 1"
• Material: Steel
• Port Ends: Female NPTF, Female ORB, Male ORB (1/4" size), Female BSPP
• Valve Options: Ball or Poppet
• Seal Options on poppet valves: Nitrile, EPR, Fluorocarbon, Neoprene

Markets:
• Agriculture
• Industrial
• Construction

Features/Benefits:
• Valve option styles are ball or poppet
• Hardened locking ball groove resists wear for increased durability and protection from Brinelling
• Shielded valve and positive valve stop prevents flow checking for smooth performance

Applications:
• Hydraulic Loaders
• Add-on hydraulic circuits
• Hydraulic tools

Specifications

Maximum Working Pressure (psi)	3000
Body Size (inch)	1
Flow Rate (GPM)	50
Seal Material	Nitrile
Media	Hydraulic
Coupling Half	Nipple
Minimum Working Temperature (F)	-40
Maximum Working Temperature (F)	250
Body Material	Steel
Thread Style	Female
Connection Type	NPTF
Plating	Zinc with clear trivalent chromate
Application	Hydraulic \| general purpose

PARKER HANNIFIN 4010-6P Cross Reference

We have 2 alternatives for the 4010-6P by PARKER HANNIFIN:
