(888) 312-8812 Login SignupFLEETGUARD LF17502 Engine Oil Filter - 10.24 in. Height, 4.32 in. (Largest OD)
Tap to view 4 more
MSRP: $68.82
$3399
Save $34.83
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 6
FLEETGUARD LF17502 Part Description
Manufacturer
Features & Benefits
- Gasket structure maintains grip after repeated contact with heated mounting pads
- Upper ribbing aids rotation during tool-free removal in tight compartments
- Filter mass assists steady alignment during blind installation angles
- Housing proportions help avoid interference with surrounding coolant hoses
Fleetguard Engine Oil Filter
The Fleetguard Engine Oil Filter offers a tall 10.24-inch profile and a 4.32-inch largest outside diameter, giving it a substantial filtration footprint for engines that circulate high oil volume over extended intervals. Its internal pathways promote steady lubrication during cold starts, hot-weather hauling, or irregular driving patterns that cycle between idle and sustained load. Despite the large dimensions, the filter is surprisingly manageable to handle during service, and its body arrangement helps prevent hand slippage even in cramped engine bays. Fleetguard’s construction approach emphasizes long-interval consistency, allowing this filter to stay viable through varied operating temperatures and oil-flow demands. The Fleetguard LF17502 seamlessly integrates into service plans that rely on uninterrupted engine lubrication.
FLEETGUARD LF17502 Specifications
Product Attributes
| Height | 10.24 in. (260.1 mm) |
| Gasket Outside Diameter | 4.02 in. (102.11) |
| Notes | By-Pass, Spin-On, Upgraded Version of LF3654 |
| Outside Diameter (Largest) | 4.32 in. (109.73 mm) |
| Standpipe | No |
| Thread Size | M35 x 16 UN-2B |
| BPV Setting | No |
| Largest Od | 4.315 inch |
| Overall Height | 260 mm |
| Thread Diameter | 1.375 in |
| Thread Form | Unified National |
| Thread Pitch | 16.0 threads Per Inch |
| Gasket Inside Diameter | 3.70 inch |
| Efficiency Test Std | ISO 4548-12 |
| Length | 10.24 inch |
| Media Type | Cellulose |
| Test Specification | ISO 4548-12 |
| Rated Flow | 10.80 L/m |
| Gasket Od | 4.02 inch |
| Hydrostatic Burst Minimum | 246.50 psi |
| Primary Particle Efficiency | 16.00 micron (c) @ 98.7% |
| Pressure Valve | No |
Additional Information
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Time | 1 |
| Warranty Time UOM | YR |
FLEETGUARD LF17502 Part Interchanges
| Brand | Part Number |
|---|---|
| Baldwin | B7409 |
| Volvo | 21707132, 21170573 |
| Wix | WL10106 |
| Mann-Filter | WP111023 |
| Atlas-Copco | 2914960300 |
| DAF | 1533639 |
| Hengst | H200WN01 |
| Renault | 7421561284, 7423114217 |
| Mack | 21707135, 21707132 |
| NAPA | 400106 |
| Nissan | 5221170573, 5221706532 |
| Carquest | 96322 |
| Donaldson | P550425 |
| Fleetguard | LF3654 |
| Hastings | LF675 |
| FRAM | P9407 |
FLEETGUARD LF17502 Cross References
We have 15 alternatives for the LF17502 by FLEETGUARD:
FLEETGUARD LF17502 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD LF17502 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
