(888) 312-8812 Login SignupCENTRIC 123.65002 C-Tek Standard Brake Drum
*Representative image - actual part not displayed
Special Order Item
Call us at (888) 312-8812
Speak with a customer service representative who can quote the price over the phone.
CENTRIC 123.65002 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.65002 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.227 |
| Weight [cntrc] Lbs | 11.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 61.722 |
| Hub Hole / Register [cntrc] In | 2.430 |
| Height [cntrc] Mm | 69.342 |
| Height [cntrc] In | 2.730 |
| Friction Surface Width [cntrc] Mm | 54.610 |
| Friction Surface Width [cntrc] In | 2.150 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 294.894 MM |
| Outside Diameter | 11.610 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.494 MM |
| Mounting Hole Diameter | 0.610 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590014006 |
CENTRIC 123.65002 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | BD60061, E128-70-007, E127-70-007, 8195, 123.65002, 8195G, D1UZ1126A, AB1126C, C1UU1126A, 140130, PDR0130, 202950, 6401103, 934, AD8502, D2626, E12770007, 87087, X21206, BD1097, 2626, 2626R, 2626DGS, 8842002, 17738 |
CENTRIC 123.65002 Fits Vehicles
- Ford Econoline (1962-1967)
- Ford Custom (1949-1952)
- Ford Victoria (1951-1954)
- Ford Deluxe (1949-1951)
- Ford Crestline (1952-1954)
- Ford E-100 Econoline (1969-1974)
- Ford Customline (1952-1954)
- Ford Country Squire (1950-1951)
- Ford Club Wagon (1962-1967)
CENTRIC 123.65002 Cross References
We have 1 alternatives for the 123.65002 by CENTRIC:
CENTRIC 123.65002 Customer Reviews
No reviews yet
Be the first to review this product!
