Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Weight [cntrc] Lbs 17.800
Weight [cntrc] Kgs 8.090
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Disc Mounting [cntrc] Floating
Product Grade [cntrc] Standard
Discard Thickness 0.945 IN
Discard Thickness 24.000 MM
Nominal Thickness 1.024 IN
Nominal Thickness 26.000 MM
Overall Height 1.980 IN
Overall Height 50.300 MM
Outside Diameter 296.000 MM
Outside Diameter 11.654 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 2.677 IN
Center Hole Diameter 68.000 MM
Mounting Bolt Hole Circle Diameter 114.300 MM
Mounting Bolt Hole Circle Diameter 4.500 IN
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 0.504 IN
Stud/Lug Hole Diameter 12.800 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305030
UPC 805890862161

Part Interchanges

Fits Vehicles

  • Renault Safrane (2010-2015)
