GATES 24C4108 Part Description
Manufacturer
Product Description
G-Force C12 Continuously Variable Transmission (CVT) Belt
Application Summary
1992-1990 Kawasaki, Mule 2010, 540cc, Drive
Features & Benefits
- Advanced carbon cord results in high modulus with extraordinary strength for faster acceleration, improved throttle response and consistent shifting performance
- Trapezoidal top cog with rounded bottom cog provides excellent flexibility and efficiency
- Aramid fiber-loaded elastomer compound for durability and optimized performance
- Maintains peak power throughout the shift curve
- Tested under extreme conditions in controlled environments as well as on race vehicles
GATES 24C4108 Specifications
Product Attributes
| Type | Power Sport High Performance CVT Belt |
| Cross Section Designation | RVS-R |
| Angle | 28 |
| Top Width | 1.25 in |
| Outside Circumference | 42.25 in |
| Construction | Double Notched |
| Notched | Yes |
| Belt Material | Chloroprene |
| Cord Material | Carbon |
| Bottom Material | Yes |
| Color | Black |
| Grade Type | OE Improved |
| Top Width | 32 mm |
| Outside Circumference | 1073 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| UPC | 00770075684770 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES 24C4108 Part Interchanges
| Brand | Part Number |
|---|---|
| Carlisle | UA439, UA442 |
| Dayco | HP2024, HP2026 |
| Carquest | 24G4108 |
| Goodyear | 31GBS1072 |
| NAPA Belts/Hose | 24G4108, 24C4108 |
| Kawasaki | 59011-1053, 59011-1077 |
| Timken | UA442, UXP442, UHQ442, UA439 |
GATES 24C4108 Fits Vehicles
- Kawasaki KAF620 Mule 4010 Trans 4x4 FE (2021-2023)
- Kawasaki KAF620 Mule 4010 4x4 FE (2021-2023)
- Kawasaki KAF620 Mule 4000 Trans (2018-2021)
- Kawasaki KAF620 Mule 4010 Trans 4x4 Camo (2014-2023)
- Kawasaki KAF620 Mule 4010 Trans 4x4 SE (2016-2018)
- Kawasaki KAF620 Mule 4010 4x4 SE (2016-2018)
- Kawasaki KAF540 Mule 2020 (1990)
- Kawasaki KAF540 Mule 2030 (1991)
- Kawasaki KAF540 Mule 2010 (1990)
- Kawasaki KAF620 Mule 4010 Trans 4x4 (2009-2023)
- Kawasaki KAF620 Mule 4010 4x4 (2009-2023)
- Kawasaki KAF620 Mule 4000 (2009-2023)
- Kawasaki KAF620 Mule 3010 Trans 4x4 (2005-2008)
- Kawasaki KAF620 Mule 3020 (2001-2003)
- Kawasaki KAF620 Mule 3010 4x4 (2001-2008)
- Kawasaki KAF620 Mule 3000 (2001-2008)
