(888) 312-8812 Login SignupDELPHI FG1677 Fuel Pump Module Assembly
Tap to view 50 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI FG1677 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1677 Specifications
Product Attributes
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 138.0 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | No |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 180.0 82 |
| Resistance Ohms Full | 10.0 82 |
| Internal Or External Strainer | Internal |
| Average Current Draw | 10 68 |
| Average Flow Rating | 55 GPH |
| Pump Type | Electric |
| Fuel Level Sender Assembly Included | Yes |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Instruction Sheet |
| System Pressure | 65 psi |
| Vapor Pressure Sensor | No |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Remanufactured Part | N |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604241905 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1677 Part Interchanges
| Brand | Part Number |
|---|---|
| Motorcraft | PFS-1098, PFS-970, PS-950 |
| Spectra Premium | SP2480M |
| AutoZone | CFG1677 |
| Ford | CT4Z 9A299-A, CT4Z 9A299-B, CT4Z 9H307-F, CT4Z-9H307-E, DT4Z 9H307-B, DT4Z 9H307-C |
| Airtex | E2591M |
