Delphi FG1616 - Fuel Transfer Unit
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
DELPHI part description
Product Description
Fuel Transfer Unit
Product Attributes
| Position(s) | Left |
| Vapor Pressure Sensor | No |
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Transfer Unit w/Float Arm, Instruction Sheet |
| Outlet Outside Diameter | 0.313 IN |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Terminal Type | Pin |
| Gasket Or Seal Included | No |
| Terminal Quantity | 3 |
| Terminal Gender | Male |
| Strainer Included | No |
| Inlet Type | Quick Connect |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 990.0 82 |
| Resistance Ohms Full | 50.0 82 |
| Internal Or External Strainer | Internal |
| Inlet Outside Diameter | 7.9 MM |
| Suction Pipe Included | No |
| Housing Material | Plastic |
| Hose Material | Nylon |
| Fuel Tank Pressure Sensor Included | No |
| Hose Outside Diameter | 11.8 MM |
| Outlet Outside Diameter | 7.9 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604240601 |
| VMRS Code | 044001089 |
| UNSPSC | 25172411 |
Part Interchanges
Fits Vehicles
- Mercedes-Benz C250 (2012-2015)
