DAYCO part description

Product Description

PREMIUM OEM REPL BALANCER, POWERBOND

Product Attributes

Overall Outside Diameter 6.563 in
Overall Outside Diameter 166.70 mm
Crank Bore 1.182 in
Crank Bore 30.00 mm
Overall Width 1.705 in
Overall Width 43.30 mm
Nose Outside Diameter 1.693 in
Nose Outside Diameter 43.00 mm
Ring Width 1.182 in
Ring Width 30.00 mm
Bolt Hole Quantity 0
Crank Trigger/Exciter Plate No
Woodruff Key Included No
Hardware Included No
Counterweight Balance Neutral, no counterweight
Timing Marks Yes
Installation Instructions Included No
Number of Integrated Pulleys 1
Pulley 1 Type Serpentine
Pulley 1 Outside Diameter 6.339 in
Pulley 1 Outside Diameter 161.00 mm
Pulley 1 Number Of Grooves 7 mm
Outer Ring Material Cast Iron

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8483509080
UPC 09317010013755

Fits Vehicles

  • Acura ILX (2013-2015)
  • Honda Crosstour (2012-2015)
  • Honda Civic (2012-2015)
  • Honda CR-V (2010-2014)
  • Acura TSX (2009-2014)
  • Honda Accord (2008-2012)
