(888) 312-8812 Login SignupCENTRIC 120.47034 Centric Premium Brake Rotor
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.47034 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
CENTRIC 120.47034 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 2 |
| Hat Id [cntrc] In | 5.898 |
| Weight [cntrc] Lbs | 19.150 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 149.800 |
| Weight [cntrc] Kgs | 8.700 |
| OEM Vane Count [cntrc] | 54 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28.000 MM |
| Hat Finish | Coated |
| Overall Height | 56.800 MM |
| Overall Height | 2.236 IN |
| Outside Diameter | 293.000 MM |
| Outside Diameter | 11.535 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.287 IN |
| Center Hole Diameter | 58.100 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.504 IN |
| Stud/Lug Hole Diameter | 12.800 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590001457 |
CENTRIC 120.47034 Cross References
| Brand | Part Number |
|---|---|
| N/A | BR90136202, 44881, 90013026, 26300AL000 |
| PRONTO | BR90136202 |
| RAYBESTOS | 981957, 981957FZN, 981957R, 581796, 581796R, 581796FZN, 981957R2 |
| Raybestos Brakes | 981957, 981957FZN, 981957R |
CENTRIC 120.47034 Fits Vehicles
- Subaru Legacy (2015-2019)
