Centric 128.33152 - Centric Premium OE Style Drilled Brake Rotor
$1,08199
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium OE Style Drilled Brake Rotor
Features & Benefits
- Premium rotors feature 100% fully machined finishes including rotor hats. This extra process provides better rotor balance and creates a cleaner; more finished looking component
Product Attributes
| Weight [cntrc] Kgs | 14.560 |
| OEM Vane Count [cntrc] | 45 |
| Vane Style [cntrc] | Curved |
| Hat Id [cntrc] In | 5.661 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 32.100 |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] Mm | 143.800 |
| Misc Holes [cntrc] | 1 |
| Discard Thickness | 34.400 MM |
| Discard Thickness | 1.354 IN |
| Nominal Thickness | 36.000 MM |
| Nominal Thickness | 1.417 IN |
| Hat Finish | Coated |
| Overall Height | 52.300 MM |
| Overall Height | 2.059 IN |
| Outside Diameter | 15.315 IN |
| Outside Diameter | 389.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | X Drilled |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.681 IN |
| Center Hole Diameter | 68.100 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.200 MM |
| Stud/Lug Hole Diameter | 0.598 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | DE |
| UPC | 805890984696 |
Part Interchanges
Fits Vehicles
- Audi RS7 (2014-2018)
